Function
It is suitable for cold shearing of metal profiles and metal structural parts with various cross-section shapes to process them into qualified charge. It is suitable for steel industry, non-ferrous metal industry, scrap steel processing and distribution center (base), renewable resource processing enterprises and scrap car dismantling enterprises.
Features
1. Mechanical, electrical and hydraulic integrated control; It can be started and stopped at any position, easy to realize overload protection; It can be equipped with diesel engine as backup power supply.
2. According to the use of the need to choose a single, continuous operation.
3. The installation of the equipment without anchor bolt fixed, convenient production or equipment layout adjustment.
Technical Specification
|
Model
|
Max. Shear Force
(ton)
|
Blade length
(mm)
|
Max.Cutting Size
(kw)
|
Shearing Frequency
(times/)
|
Motor
(kw)
|
|
Q43-63
|
63
|
600/800
|
30×30φ40
|
10-12
|
7.5
|
|
Q43-120
|
120
|
600/800
|
50×50φ55
|
10-12
|
15
|
|
Q43-160
|
160
|
700/800
|
55×55φ63
|
10-12
|
18.5
|
|
Q43-200
|
200
|
800/1000
|
65×65φ70
|
10-12
|
22
|
|
Q43-250
|
250
|
1000/1200
|
70×70φ80
|
10-12
|
2×15
|
|
Q43-315
|
315
|
1000/1200
|
75×75φ85
|
10-12
|
2×18.5
|
|
Q43-400
|
400
|
1500
|
90×90φ100
|
8-11
|
2×22
|
|
Q43-500
|
500
|
1500
|
100×100φ110
|
8-11
|
2×30
|
|
Q43-630
|
630
|
1600
|
110×110φ120
|
4-8
|
2×37
|
